Premium-quality forged fittings manufactured for superior strength, leak-proof performance, and exceptional durability in high-pressure piping systems across oil & gas, petrochemical, power generation, marine, and process industries.
Simplex Metal is a trusted manufacturer, supplier, and exporter of premium-quality Forged Fittings designed for high-pressure and high-temperature piping systems. Manufactured from premium-grade raw materials, our forged fittings provide exceptional strength, leak-proof performance, excellent dimensional accuracy, and outstanding corrosion resistance.
Our comprehensive range includes Socket Weld Fittings, Threaded Fittings, Elbows, Tees, Couplings, Unions, Bushings, Caps, Plugs, Crosses, Street Elbows, Hex Nipples, Reducers, and Outlets in Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel, Super Duplex Steel, and Nickel Alloy grades.
Widely used in Oil & Gas, Petrochemical, Power Generation, Chemical Processing, Marine, Offshore, Water Treatment, Pharmaceutical, and Process Industries, our Forged Fittings are manufactured in accordance with international standards to ensure safe, reliable, and long-lasting performance in demanding industrial applications.
Our Carbon Steel Forged Fittings are manufactured in accordance with international standards to provide superior strength, leak-proof connections, and reliable performance for high-pressure piping systems across a wide range of industrial applications.
| Specification | Details |
|---|---|
| Standards | ASME B16.11, MSS SP-79, MSS SP-83, MSS SP-95, MSS SP-97, ASTM, ASME, DIN, EN, JIS |
| Available Grades | ASTM A105, ASTM A350 LF2, ASTM A694 F42, F46, F52, F60, F65, F70 |
| Product Types | Socket Weld Elbow, Socket Weld Tee, Socket Weld Cross, Full Coupling, Half Coupling, Reducing Coupling, Socket Weld Union, Threaded Elbow, Threaded Tee, Threaded Cross, Threaded Coupling, Threaded Union, Hex Nipple, Street Elbow, Bushing, Plug, Cap |
| Pressure Rating | Class 2000, 3000, 6000, 9000 |
| Size Range | 1/8" NB to 4" NB |
| Connection Type | Socket Weld, Threaded (NPT, BSPT, BSPP) |
| Manufacturing Process | Closed Die Forged, Precision Machined, Heat Treated |
| Surface Finish | Black Painted, Anti-Rust Oil, Zinc Coated, Hot Dip Galvanized |
| Testing | PMI, Hydrostatic Test, Hardness Test, Ultrasonic Test, Dimensional Inspection, Third-Party Inspection |
| Applications | Oil & Gas, Petrochemical, Refineries, Power Plants, Offshore, Marine, Chemical Processing, Water Treatment, Industrial Piping |
Our Stainless Steel Forged Fittings are manufactured to international standards, providing exceptional corrosion resistance, excellent mechanical strength, and reliable leak-proof performance for critical industrial piping systems.
| Specification | Details |
|---|---|
| Standards | ASME B16.11, MSS SP-79, MSS SP-83, MSS SP-95, MSS SP-97, ASTM, DIN, EN, JIS |
| Available Grades | ASTM A182 F304, F304L, F310, F310S, F316, F316L, F317L, F321, F347, F904L |
| Product Types | Socket Weld Elbow, Socket Weld Tee, Socket Weld Cross, Full Coupling, Half Coupling, Reducing Coupling, Socket Weld Union, Threaded Elbow, Threaded Tee, Threaded Cross, Threaded Coupling, Threaded Union, Hex Nipple, Street Elbow, Bushing, Plug, Cap |
| Pressure Rating | Class 2000, 3000, 6000, 9000 |
| Size Range | 1/8" NB to 4" NB |
| Connection Type | Socket Weld, Threaded (NPT, BSPT, BSPP) |
| Manufacturing Process | Closed Die Forged, CNC Machined, Heat Treated |
| Surface Finish | Pickled, Passivated, Polished, Machined |
| Testing | PMI, Hydrostatic Test, Ultrasonic Test, Hardness Test, Third-Party Inspection |
| Applications | Chemical Processing, Pharmaceutical, Food Processing, Marine, Offshore, Oil & Gas, Petrochemical, Water Treatment |
Our Alloy Steel Forged Fittings are designed for elevated temperature and high-pressure services, delivering superior strength, toughness, and long-term performance in demanding industrial environments.
| Specification | Details |
|---|---|
| Standards | ASME B16.11, MSS SP-79, MSS SP-83, MSS SP-95, MSS SP-97, ASTM, DIN, EN, JIS |
| Available Grades | ASTM A182 F1, F5, F9, F11, F12, F22, F91 |
| Product Types | Socket Weld Elbow, Socket Weld Tee, Socket Weld Cross, Full Coupling, Half Coupling, Reducing Coupling, Socket Weld Union, Threaded Elbow, Threaded Tee, Threaded Cross, Threaded Coupling, Threaded Union, Hex Nipple, Street Elbow, Bushing, Plug, Cap |
| Pressure Rating | Class 2000, 3000, 6000, 9000 |
| Size Range | 1/8" NB to 4" NB |
| Connection Type | Socket Weld, Threaded (NPT, BSPT, BSPP) |
| Manufacturing Process | Closed Die Forged, Heat Treated, Precision CNC Machined |
| Surface Finish | Anti-Rust Oil, Black Painted, Zinc Coated, Machined |
| Testing | PMI, Ultrasonic Test, Hardness Test, Hydrostatic Test, Third-Party Inspection |
| Applications | Boilers, Heat Exchangers, Refineries, Petrochemical Plants, Power Plants, High-Pressure Piping, Oil & Gas |
Our Duplex Steel Forged Fittings combine high mechanical strength with exceptional corrosion resistance, making them suitable for offshore, marine, petrochemical, and other demanding industrial applications.
| Specification | Details |
|---|---|
| Standards | ASME B16.11, MSS SP-79, MSS SP-83, MSS SP-95, MSS SP-97, ASTM, DIN, EN, JIS |
| Available Grades | ASTM A182 F51, ASTM A182 F60, UNS S31803, UNS S32205, Duplex 2205, Duplex 2304 |
| Product Types | Socket Weld Elbow, Socket Weld Tee, Socket Weld Cross, Full Coupling, Half Coupling, Reducing Coupling, Socket Weld Union, Threaded Elbow, Threaded Tee, Threaded Cross, Threaded Coupling, Threaded Union, Hex Nipple, Street Elbow, Bushing, Plug, Cap |
| Pressure Rating | Class 2000, 3000, 6000, 9000 |
| Size Range | 1/8" NB to 4" NB |
| Connection Type | Socket Weld, Threaded (NPT, BSPT, BSPP) |
| Manufacturing Process | Closed Die Forged, CNC Machined, Heat Treated |
| Surface Finish | Pickled, Passivated, Machined, Anti-Rust Protected |
| Testing | PMI, Hydrostatic Test, Ultrasonic Test, Ferrite Test, Hardness Test, Third-Party Inspection |
| Applications | Offshore, Marine, Oil & Gas, Petrochemical, Chemical Processing, Desalination Plants, Water Treatment |
Our Super Duplex Steel Forged Fittings provide outstanding resistance to pitting, crevice corrosion, and chloride stress corrosion cracking while maintaining exceptional strength in severe service environments.
| Specification | Details |
|---|---|
| Standards | ASME B16.11, MSS SP-79, MSS SP-83, MSS SP-95, MSS SP-97, ASTM, DIN, EN, JIS |
| Available Grades | ASTM A182 F53, ASTM A182 F55, UNS S32750, UNS S32760, Super Duplex 2507, Zeron 100 |
| Product Types | Socket Weld Elbow, Socket Weld Tee, Socket Weld Cross, Full Coupling, Half Coupling, Reducing Coupling, Socket Weld Union, Threaded Elbow, Threaded Tee, Threaded Cross, Threaded Coupling, Threaded Union, Hex Nipple, Street Elbow, Bushing, Plug, Cap |
| Pressure Rating | Class 2000, 3000, 6000, 9000 |
| Size Range | 1/8" NB to 4" NB |
| Connection Type | Socket Weld, Threaded (NPT, BSPT, BSPP) |
| Manufacturing Process | Closed Die Forged, CNC Machined, Heat Treated |
| Surface Finish | Pickled, Passivated, Precision Machined, Anti-Rust Protected |
| Testing | PMI, Hydrostatic Test, Ultrasonic Test, Ferrite Test, Hardness Test, Third-Party Inspection |
| Applications | Offshore, Marine, Oil & Gas, Petrochemical, Chemical Processing, Heat Exchangers, Desalination Plants, High-Chloride Environments |
Our Nickel Alloy Forged Fittings are engineered for highly corrosive and elevated temperature applications, providing exceptional mechanical strength, superior oxidation resistance, and long-term reliability in critical industrial environments.
| Specification | Details |
|---|---|
| Standards | ASME B16.11, MSS SP-79, MSS SP-83, MSS SP-95, MSS SP-97, ASTM, ASME, DIN, EN, JIS |
| Available Grades | ASTM B564 Inconel 600, Inconel 625, Inconel 718, Incoloy 800, Incoloy 800H, Incoloy 825, Monel 400, Monel K500, Hastelloy C22, Hastelloy C276, Nickel 200, Nickel 201 |
| Product Types | Socket Weld Elbow, Socket Weld Tee, Socket Weld Cross, Full Coupling, Half Coupling, Reducing Coupling, Socket Weld Union, Threaded Elbow, Threaded Tee, Threaded Cross, Threaded Coupling, Threaded Union, Hex Nipple, Street Elbow, Bushing, Plug, Cap |
| Pressure Rating | Class 2000, 3000, 6000, 9000 |
| Size Range | 1/8" NB to 4" NB |
| Connection Type | Socket Weld, Threaded (NPT, BSPT, BSPP) |
| Manufacturing Process | Closed Die Forged, Precision CNC Machined, Heat Treated |
| Surface Finish | Pickled, Passivated, Precision Machined, Polished |
| Testing | PMI, Hydrostatic Test, Ultrasonic Test, Hardness Test, Chemical Analysis, Dimensional Inspection, Third-Party Inspection |
| Applications | Chemical Processing, Petrochemical, Offshore Platforms, Marine, Oil & Gas, Aerospace, Power Generation, Heat Exchangers, Pressure Vessels, Nuclear Industry |
